Reliable Pre-Filtration Solutions for Paint, Coating & Ink Manufacturing in Vietnam

1. Client Background

Our client is a Vietnam-based manufacturer and supplier of paints, coatings, inks, and other chemical products. With growing production demands and increasingly strict quality requirements, they needed a more efficient and reliable filtration system to improve product purity and protect downstream equipment.

2. Initial Inquiry & Requirements

The client approached us with the following initial needs:

| Item | Requirement |
| ---- | ----------- |
| Application | Ink pre-filtration – self-cleaning filter |
| Flow rate | 5,000 L/h (5 m³/h) |
| Viscosity | < 8,000 cps |
| Impurity content | < 1,000 ppm |
| Secondary filtration | Bag filter unit (4-bag type) – they already had one 4-bag unit in operation and needed an additional pre-filter as well as more bag filter capacity for secondary polishing |

3. Engineering Recommendations – First Order

Based on the client's specifications, our engineering team provided the following initial recommendations:

Pre-filtration (self-cleaning): Model 219 self-cleaning filter, 125 μm filtration precision, suitable for 5 m³/h flow rate.
Bag filter unit (secondary): 4-bag type, material – SS304 stainless steel.

Later, the client revised their requirement by changing the filtration precision to 20 μm. In response, our team recommended the 325-Scraper Automatic Self-cleaning Filter, a model specially designed for paint and similar viscous applications. This unit features:

Internal scraper + spiral structure
Filtration precision: 20 μm
Excellent performance for high-precision filtration of viscous liquids

The client accepted this recommendation and placed their first order for the self-cleaning filter. We then modified our production drawings according to the client's drawings to ensure a perfect fit.

4. Repeat Orders – Within Six Months

Within less than 3 months after the first delivery, the client placed additional repeat orders, including:

1 unit of Model 500 Spiral Scraper Self-cleaning Filter
5 units of Model 325 Spiral Scraper Self-cleaning Filter (identical to the first unit)

This strong repeat business clearly demonstrates the client's satisfaction with both the product performance and our after-sales support.

5. Spare Parts Recommendation

In addition to the main filter units, the client also purchased spare screens and filter bags for future replacement. We highly recommend that all clients consider ordering spare parts together with the main equipment to avoid unexpected downtime and production delays. Being prepared in advance always saves time and trouble later.
