1.5 cubic meters per hour - RO pure water system
Basic Information
Model
JX-PW-C1.5
Unit
set
Category
RO System
Delivery Time
30 Days
Package Size
1x1x1 mm
Package Weight
1 KG
Product Images
Technical Specifications
Main Unit
| Parameter | Specification | Unit | Notes |
|---|---|---|---|
| Model | JX-PW-C1.5 | — | — |
| Inlet Water Flow | 2-3 | m3/h | — |
| Outlet Water Flow | 1.5 | m3/h | — |
| Inlet Water Quality | TOC 1000 ppm，TDS 15000 ppm | ppm | — |
| Outlet Water Quality | TOC ＜40 ppm，TDS ＜2000 ppm | ppm | — |
| Material | stainless steel | — | — |
Preprocessing Section
| Parameter | Specification | Unit | Notes |
|---|---|---|---|
| Raw Water Pump | H=33m，stainless steel | PCS | 1 PCS |
| Multi-media Filter | Ф400×1450 | Set | 1 PCS |
| Quartz Sand Filter | 0.5-4mm | Set | 1 PCS |
| Activated Carbon Filter | Ф400×1450 | Set | 1 PCS |
| Security Filter | 5-core 20-inch；SS316 | Set | 1 PCS |
| RO System | 1 | Set | putamina;4PCS |
| EDI System | / | Set | — |
Post-Processing Section
| Parameter | Specification | Unit | Notes |
|---|---|---|---|
| Control System | PLC(RO-2008) | Set | — |
| pH Adjustment | 1 | Set | — |
| UV Sterilizer System | / | Set | — |
| Water Storage System | 1 | Pcs | — |
| Piping And Fittings | DN25-20 | Lot | — |
